공압 병 화면 프린터

공유:
단가: USD 3776 / Set/Sets
Min.Order 단가
1 Set/Sets USD 3776 / Set/Sets
지불 유형: L/C,T/T
Terms of Trade: FOB,CIF,EXW,FCA,CPT
최소 주문량: 1
단가: USD
기본 정보
모형:S-220S
인쇄판의 종류: 스크린 프린터
해당 산업: 전원, 소매, 건설 작업
보증 제외 서비스: 비디오 기술 지원, 온라인 지원, 예비 부품, 현장 유지 보수 및 수리 서비스
현지 서비스 제공처 (해외 서비스 아울렛이있는 국가): 이탈리아, 베트남, 페루, 파키스탄, 러시아, 일본, 모로코
쇼룸 위치 (해외 샘플 룸이있는 국가): 사우디 아라비아, 인도, 스페인, 케냐, 칠레, 알제리, 방글라데시, 우크라이나
상태: 새로운
원산지: 중국
사용하다: 라벨 프린터, 빌 프린터
자동화 정도: 반자동
색상 번호 및 표면 번호 인쇄: 단색
보증 기간: 일년
핵심 판매 포인트: 저소음, 멀티 컬러
마케팅 유형: 일반 제품, 신제품 2019
기계적 테스트 보고서: 제공
비디오 공장 검사: 제공
핵심 부품 보증 기간: 일년
핵심 구성 요소: PLC, 엔진
Additional Info
포장: 나무 케이스
생산력: 50 sets / month
상표: KC
수송: Ocean
원산지: Dongguan
지원에 대한 지원: 50 sets/month
인증 : CE Certificate
포트: Shenzhen,Guangzhou,Hongkong
제품 설명

샘플이 보여줍니다

255

기계 설명

S-220S Multi-function screen printing machine//Usage and characters

  • 220mm in diameter, suitable for printing less, hollow plastic bottles, hose, there is a slight taper of the hard and soft surface material color screen.
  • Used in baby bottles, cosmetic bottles, medicine bottles, filters, ignition and other hollow containers monochrome screen printing;
  • With surface UV curing machine M-1030UVS can be UV screen printing of plastic containers;
  • Solvent ink for screen printing, UV screen printing inks, screen printing ink printing a variety of functions;
  • Upper and lower part of table type surface screen printing machine, take place after the table automatically lifting the work piece;
  • You can use the foot switch for automatic operation, the safety factor greatly increased;
  • Multi-type screen printing machine, Both printing round objects and printing taper and flat objects, hardware replacement only way a simple gas conversion, will be able to achieve a multifunctional , and reduce costs.

Application

Plastics soft tubes, Bottles, containers, Bucket, Cosmetic case, any Cylinder-object, Oval-object.


S-220S Multi-function screen printing Machine //Parameters

  • Max. printing height: 320 mm;
  • Max. Printing diameter:;whole circle: 220 mm;.arc: 680 mm;
  • Max. printing speed: 1000 pcs/hr;
  • Air consume: 80 Litre/min(6bar).
  • Max Screen Frame: 850×450mm;
  • Stroke up-and-down of working table: 150mm;
  • Stroke up-and-down of Squeegee: 50mm;
  • Max length of printing objects: 400mm;
  • Range back-forth of Squeegee: 250mm;
  • Diameter of Fixture axis: 18mm;
  • Range back-forth of screen frame: 180mm
  • Works supply: 110V-220V Power supply;5-7 Bar compress air;
  • Package Dimension: 1130*1560*1360mm;
  • Gross weight: 190kg;
  • CBM: 2.3974
  • H.S.CODE: 8443198000
  • Certificate: CE


S-220S Multi-function screen printing Machine//Advantage

  • Choose clamp-type Workbench can be inflatable, or may not be blowing, can be placed all types of round, oval-shaped substrates;
  • Contact with the substrate , Working table up and down, to facilitate the placement of the substrates and removed;
  • High Precision axis control. Working table up and down, smooth running, accuracy up to 0.07mm;
  • High Precision axis control movement. Screen printing pressure is uniform and reliable, the accuracy up to 0.07mm;
  • Self-balance scraper technology and back blade, to ensure uniformity of ink, ink formation;
  • Microcomputer control program operations, set up a variety of modes;
  • Four counts digital LED count, high degree of automation;
  • Printed Stroke mechanical adjustments, adjust the speed of integrated circuit digital.
  • Around the screen frame, up and down the emblem of the tune, overlay accuracy, tuning and quick
